- Brand: REEDMORAL
- SKU: LDH267
- Product Type: Carburetor assembly
- Application: Selected Ford 1.6L and compatible conversion applications requiring a 32/36 progressive carburetor with the shown U-shaped linkage bracket
- Reference Numbers: WEBER 32/36
LDH267 REEDMORAL 32/36 Progressive Carburetor for Ford 1.6L with U-Bracket
Description
Product Overview
The LDH267 is a brand-new REEDMORAL carburetor assembly, newly manufactured rather than rebuilt or remanufactured.
- Application: Selected Ford 1.6L and compatible conversion applications requiring a 32/36 progressive carburetor with the shown U-shaped linkage bracket
- Reference Numbers: WEBER 32/36
- Configuration: Progressive twin-barrel downdraft configuration with U-shaped linkage bracket; distinct from LDH259 external-linkage variants
Factory Calibration Specifications
Factory-recorded baseline values. Final tuning may vary with the complete engine and vehicle setup.
| Carburetor Type | 32/36 progressive |
|---|---|
| Emulsion Tube | F50 |
| Pump Jet | 60 |
| Needle Valve | 2 |
| Idle Jet | 60 |
| Main Jet | 140 |
| Main Air Jet | 170 |
| Venturi | 26 / 27 |
| Auxiliary Venturi | 10.5 |
Application and Year Fitment Guide
The 32/36 designation identifies a carburetor family, not guaranteed vehicle fitment. Compare the U-shaped bracket, choke, mounting flange, fuel inlet, vacuum ports and complete linkage arrangement.
| Make / Model | Years | Engine / Setup | Fitment Check |
|---|---|---|---|
| Ford 1.6L conversion applications | Application-specific | 1.6L gasoline | Confirm the U-shaped bracket, manifold or adapter, choke and throttle-cable direction |
| Universal 32/36 conversion | No fixed model-year range | Engine and manifold dependent | Do not select by 32/36 marking alone; compare the complete external configuration |
How to Confirm Fitment
- Match the complete model and reference markings.
- Compare the mounting flange, bore arrangement, choke, fuel inlet, vacuum ports and linkage.
- Confirm the manifold or adapter, air-cleaner clearance and fuel-system requirements.
- Have a qualified installer perform synchronization, calibration and final adjustment.
Important Notes
Vehicle production changes and custom conversion parts can alter fitment. Select by complete configuration, not appearance alone.
Additional information
| Reference | WEBER 32/36 |
|---|
